产品编号

沟槽尺寸

O型圈

GB3452,

1-82d,

×d2

d

D

B

L

Rmax

E

NT-01-16

8.5

16

3.75

3.2

0.5

0.85

~

0.5

8×2.65

NT-01-18

10.5

18

10×2.65

NT-01-20

12.5

20

11.8×2.65

NT-01-22

14.5

22

14×2.65

NT-01-25

17.5

25

17×2.65

NT-01-28

20.5

28

20×2.65

NT-01-30

22.5

30

21×2.65

NT-01-32

24.5

32

23.6×2.65

NT-01-35

27.5

35

26.5×2.65

NT-01-40

29.0

40

5.5

4.2

0.7

0.85

~

0.5

28×3.55

NT-01-45

34.0

45

33.5×3.55

NT-01-50

39.0

50

38.7×3.55

NT-01-55

44.0

55

43.7×3.55

NT-01-60

49.0

60

47.5×3.55

NT-01-63

52.0

63

50×3.55

NT-01-65

54.0

65

53×3.65

NT-01-70

59.0

70

58×3.55

NT-01-75

64.0

75

63×3.55

NT-01-80

64.5

80

7.75

6.3

1.2

1

~

0.6

63×5.3

NT-01-85

69.5

85

69×5.3

NT-01-90

74.5

90

73×5.3

NT-01-100

84.5

100

82.5×5.3

NT-01-110

94.5

110

92.5×5.3

NT-01-120

104.5

120

103×5.3

NT-01-125

109.5

125

109×5.3

NT-01-130

114.5

130

112×5.3

NT-01-140

124.5

140

122×5.3

NT-01-150

129

150

10.5

8.1

1.5

1.25

~

0.6

127×7

NT-01-160

139

160

136×7

NT-01-170

149

170

145×7

NT-01-180

159

180

155×7

NT-01-190

169

190

165×7

NT-01-200

179

200

175×7

NT-01-210

189

210

185×7

NT-01-220

199

220

198×7

NT-01-230

209

230

200×7

NT-01-240

219

240

212×7

NT-01-250

229

250

224×7

NT-01-260

339

260

236×7

NT-01-280

259

280

256×7

NT-01-290

269

290

265×7

NT-01-300

279

300

272×7

NT-01-310

289

310

280×7

NT-01-320

299

320

290×7
